AndoLabInstruments

1ch PZT Driver

How to use

  1. Connect DC power. Default connector is HIROSE 4pin male (as usual) on the back panel. 6-30V DC power is acceptable (15V is desired).
  2. Connect PZT to "OUT" port and apply the control voltage to "IN" port.
  3. Offset is variable by adjusting a potentiometer "OFFSET".
  4. Output voltage is [IN+OFFSET] x 10
  5. "MON" port is a mirror of "OUT" port given by OUT / 100


Transfer Function

Output Noise

Notes
